Hollis 500SE DC7 Regulator

US$599.95

Old School. New Tech. The 500SE utilizes a servo controlled valve to provide precision airflow and unparalleled performance for both air and trimix divers in a side exhaust configuration.

Clear
Category: Tag:

Description



Hollis 500SE DC7 Regulator







Old School. New Tech.


The Hollis 500SE DC7 Regulator revisits the side exhaust design, with a modern stylish design and re-engineered servo controlled valve to deliver excellent performance. Paired with a over balanced diaphragm first stage that has been designed for ideal hose routing for tech, back and side-mount configurations.

The Hollis 500SE Second Stage utilizes a Servo Controlled Valve to provide precision airflow and unparalleled performance for both AIR-and-TRIMIX divers in a side-exhaust configuration. Just the smallest, gentlest inhale starts the servo valve working as air starts to flow into the second stage, it creates a vacuum behind the diaphragm, drawing it inward and quickly opening the valve further.

The side exhaust configuration means there is no right way up, it can be used for both left and right set ups without modification. Comes with an orthodontic mouthpiece which helps to reduce jaw fatigue and improve bite comfort.

The Hollis DC7 First Stage provides progressively greater Intermediate Pressure as depth and gas density increases for superior gas delivery under the most-extreme conditions.

This regulator system is designed to withstand the Rigorous CE Standard for cold water Performance.

Specs

FEATURE & FUNCTIONS

500SE SECOND STAGE

Valve Type

Pneumatically balanced Servo valve system

Material

Chrome-plated brass

Intergrated Purge Button

Yes

Mouthpiece

Orthodontic w / Tabs

Nitrox Compatibility

Standard To 40%

Minimum Cracking Effort

0.8 CIW

Factory Set Inhalation Effort

1.0 – 1.2 CIW

Work of Breathing – 198 ft (60 m)

1.1 JOULES





FEATURE & FUNCTIONS

DC7 FIRST STAGE

Valve Type

Over-Balanced Diaphragm

Material

Machined Triple Chrome Plated Marine Brass, Stainless Valve Orifice

Low Pressure Ports

4

High Pressure Ports

2

Nitrox Compatibility

Standard To 40%

Environmental Protection

Dry Chamber

Factory Set Intermediate Pressure

138 – 142 psi

9.5 – 9.8 bar

Pressure Drop

9 psi

0.6 bar

300-Bar Din Fitting

Optional
